High Frequency Wire and Cable Spark Tester of Wire and Cable Making Machine

Name: High Frequency Wire and Cable Spark Tester of Wire and Cable Making Machine
Brand: HOOHA
Price: 850 USD

Wholesale High Frequency Wire and Cable Spark Tester of Wire and Cable Making Machine from china suppliers

Brand Name : HOOHA

Model Number : HH

Certification : CE, SGS, ISO

Place of Origin : Guangdong

MOQ : 1 set

Price : US＄850-860/1set

Payment Terms : D/A, D/P, T/T, MoneyGram

Supply Ability : 15set/1 month

Delivery Time : 15 Working Days

Packaging Details : PE film wrapped, wood frame packed as customer requiry

Usage : Testing

After-sales service : Overseas Service Provided

Voltage : 380V 50HZ

Power : AC220V 50HZ

Warranty : 1 Year

EDM sensitivity : <600μA

Output test voltage (max.) : 15,25,35KV

Sample outer diameter : 80mm,150mm

Test speed (max) : 480m/min

Electrode : 408mm

Contact Now

High Frequency Wire and Cable Spark Tester of Wire Testing Equipment

Product Description

High Frequency Wire and Cable Spark Tester of Wire and Cable Making Machine

Applications:
HOOHA Power frequency spark machine is a necessary test equipment for wire and cable manufacturing process and using high voltage to test the insulation quality. The EDM sensitivity <600μA.
Description:
Power frequency spark machine is actually an online weakness detection instrument. It periodically loads the set voltage value to the insulated wire according to a certain rule, and the conductor part is grounded. In this way, a voltage difference is formed between the conductor and the insulation surface, so that it can be detected whether the insulation layer is defective.

15kv Cable Spark Tester
Voltage indication	Pointer type
Output voltage	0-15KV
Accuracy	±3%
Sensitivity	<600μA
Maximum walking speed	180m/min
Maximum sample outer diameter	25mm
Volume(about)	160cm×50cm×130cm
Power	1phase AC 220V 50Hz(According to the country or appointment)

Power cable production line:

Related Products:

The Wire Samples

The machine is mainly used for All kinds of transparent, translucent objects, such as glass tubes,
glass rod local area network (LAN) cables, Coaxial cable, Optical fiber, flat cable, Frequency pertur
-bation cable, communication cable, Power cable, pipe, wire.
